Trek Domane SL 7 Gen 4
Trek Domane SL 7 Gen 4
Specifications
*Note: Specifications apply to all sizes unless listed separately
Chassis | 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle |
---|---|
Fork | Domane SLR carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100mm thru axle |
Chassis alignment | Endurance |
Weight | 56 - 8.26kg |
---|---|
Weight Limit | This model has an overall maximum limit (combined weight of bicycle, rider and load) of 125kg. |
*Command |
Measure: 44, 47, 50, 52, 54, 56, 58, 60, 62 Shimano Ultegra R8170 Di2, 12 speed |
---|---|
Measure: 62 Shimano Ultegra STI with Brake. Item Number: ST-R8170(L) - BR-R8170(F), 2 or 12-Speed, Hydraulic Disc Brake, Di2 Wires need to be ordered separately, Left STI, Front Caliper. (Visit si.shimano.com for compatibility, manuals and exploded views) |
|
Front derailleur | Shimano Ultegra R8150 Di2, weld-on, downward swing |
Rear derailleur | Shimano Ultegra R8150 Di2, 34T max cog |
*Crankset |
Measure: 44, 47 Shimano Ultegra R8100, 50/34, length 165mm |
Measure: 50, 52 Shimano Ultegra R8100, 50/34, length 170mm |
|
Measure: 54, 56 Shimano Ultegra R8100, 50/34, length 172.5mm |
|
Measure: 58, 60, 62 Shimano Ultegra R8100, 50/34, length 175mm |
|
Central movement | Praxis, T47 threaded, internal bearing |
Cassette | Shimano Ultegra R8100, 11-34, 12 speed |
Chain | Shimano XT M8100, 12 speed |
Max. size of the crown | 2x: 52/36 |
Front wheel | Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim profile, 100x12mm thru axle |
---|---|
Rear wheel | Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim profile, Shimano 11-speed freehub body, 142x12mm thru axle |
Rear locking | Bontrager Switch thru axle, removable lever |
Pneumatic component | Bontrager TLR Sealant, 6oz |
Max. dimensions of the tyre | 38mm without fenders, 35mm with fenders |
*Saddle |
Measure: 44, 47, 50, 52 Bontrager Verse Short Comp, steel rails, 155mm width |
---|---|
Measure: 54, 56, 58, 60, 62 Bontrager Verse Short Comp, steel rails, 145mm width |
|
*Seatpost |
Measure: 44, 47, 50, 52, 54, 56 KVF aero carbon seatpost, 20mm offset, 280mm length |
Measure: 58, 60, 62 KVF aero carbon seatpost, 20mm offset, 320mm length |
|
*Handlebar |
Measure: 44, 47 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, Di2 internal routing, 75mm reach, 128mm drop, 36cm width |
Measure: 50 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, Di2 internal routing, 75mm reach, 128mm drop, 38cm width |
|
Measure: 52 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, Di2 internal routing, 75mm reach, 128mm drop, 40cm width |
|
Measure: 54, 56 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, Di2 internal routing, 75mm reach, 128mm drop, 42cm width |
|
Measure: 58, 60, 62 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, Di2 internal routing, 75mm reach, 128mm drop, 44cm width |
|
Handlebar tape | Bontrager Supertack Perf Tape |
*Handlebar stem |
Measure: 44 Trek RCS Pro, -7 degrees, 60mm length |
Measure: 47 Trek RCS Pro, -7 degrees, 70mm length |
|
Measure: 50 Trek RCS Pro, -7 degrees, 80mm length |
|
Measure: 52, 54 Trek RCS Pro, -7 degrees, 90mm length |
|
Measure: 56, 58 Trek RCS Pro, -7 degrees, 100mm length |
|
Measure: 60, 62 Trek RCS Pro, -7 degrees, 110mm length |
|
Brake | Shimano Ultegra hydraulic disc |
Brake rotor | Shimano CL800, centerlock, 160mm |
Disk size | Max brake rotor size: 160mm front & rear |
Bag | Bontrager BITS frame bag |
---|
We reserve the right to make changes to product information on the site at any time without notice, including equipment, specifications, models, colors, materials and prices. Due to supply chain issues, compatible parts may be replaced at any time without notice.
Bike and frame weights are for pre-production painted products at the time of printing. The weight of the finished product may vary.
Measures
Measure | Rider height | Inside leg |
---|---|---|
44 |
150 - 153 cm 4'11" - 5'0" |
71 - 73 cm 28" - 29" |
47 |
152 - 158 cm 5'0" - 5'2" |
71 - 75 cm 28" - 30" |
50 |
158 - 163 cm 5'2" - 5'4" |
74 - 77 cm 29" - 30" |
52 |
163 - 168 cm 5'4" - 5'6" |
76 - 79 cm 30" - 31" |
54 |
168 - 174 cm 5'6" - 5'9" |
78 - 82 cm 31" - 32" |
56 |
174 - 180 cm 5'9" - 5'11" |
81 - 85 cm 32" - 33" |
58 |
180 - 185 cm 5'11" - 6'1" |
84 - 87 cm 33" - 34" |
60 |
185 - 190 cm 6'1" - 6'3" |
86 - 90 cm 34" - 35" |
62 |
190 - 195 cm 6'3" - 6'5" |
89 - 92 cm 35" - 36" |
