Trek
Trek Emonda SL 7 (24)
Trek Emonda SL 7 (24)
Émonda SL 7 Disc is the ultra-light carbon racing bike with an aerodynamic design designed to speed on the flats and fly up hills. The wireless Di2 electronic transmission for incredibly quick shifts, the lightweight carbon wheels and racing components make it an ideal solution for those who want to make the most of all the performance advantages.
Specifications
*Note: Specifications apply to all sizes unless listed separately
Chassis | Ultralight 500 Series OCLV Carbon, race-optimized carbon tube, tapered head tube, internal cable routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle |
---|---|
Fork | Émonda SL full carbon, tapered carbon steerer, internal brake cable routing, flat mount disc, 12x100mm thru axle |
Weight | 56 - 7.90 kg / 17.42 lbs |
---|---|
Weight Limit | This model has an overall maximum limit (combined weight of bicycle, rider and load) of 125kg. |
Charger | Charging cable supplied |
---|
Command | Shimano Ultegra R8170 Di2, 12 speed |
---|---|
Front derailleur | Shimano Ultegra R8150 Di2, weld-on, downward swing |
Rear derailleur | Shimano Ultegra R8150 Di2, 34T max cog |
*Crankset |
Measure: 47 Shimano Ultegra R8100, 52/36, length 165mm |
Measure: 50, 52 Shimano Ultegra R8100, 52/36, length 170mm |
|
Measure: 54, 56, 58 Shimano Ultegra R8100, 52/36, length 172.5mm |
|
Measure: 60, 62 Shimano Ultegra R8100, 52/36, length 175mm |
|
Central movement | Praxis, T47 threaded, internal bearing |
Cassette | Shimano Ultegra R8100, 11-30, 12 speed |
Chain | Shimano XT M8100, 12 speed |
Max. size of the crown | 1x: 50T, 2x: 53/39 |
Front wheel | Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim profile, 100x12mm thru axle |
---|---|
Rear wheel | Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim profile, Shimano 11-speed freehub body, 142x12mm thru axle |
Front locking | Bontrager Switch thru axle, removable lever |
Rear locking | Bontrager Switch thru axle, removable lever |
Tire | Bontrager R3 Hard-Case Lite, Tubeless Ready, carbon bead, 170tpi, 700x25mm |
Pneumatic component | Bontrager TLR Sealant, 6oz |
Paranipple | Bontrager TLR |
Max. dimensions of the tyre | 28mm |
Saddle | Bontrager Aeolus Comp, steel rails, 145mm width |
---|---|
*Seatpost |
Measure: 47, 50, 52, 54 Bontrager carbon seatpost terminal, 20mm offset, short length |
Measure: 56, 58, 60, 62 Bontrager alloy seat post, 20mm offset, long length |
|
*Handlebar/stem (integrated) |
Measure: 47, 50 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width, 80mm stem length |
Measure: 52 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 40cm width, 90mm stem length |
|
Measure: 54 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 90mm stem length |
|
Measure: 56 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 100mm stem length |
|
Measure: 58 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 110mm stem length |
|
Measure: 60, 62 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 44cm width, 110mm stem length |
|
Handlebar tape | Bontrager Supertack Perf Tape |
Brake | Shimano Ultegra hydraulic disc |
Brake rotor | Shimano CL800, centerlock, 160mm |
Disk size | Max brake rotor size: 160mm front and rear |
We reserve the right to make changes to product information on the site at any time without notice, including equipment, specifications, models, colors, materials and prices. Due to supply chain issues, compatible parts may be replaced at any time without notice.
Bike and frame weights are for pre-production painted products at the time of printing. The weight of the finished product may vary.
Measures
Measure | Rider height | Inside leg |
---|---|---|
47 |
152 - 158 cm 5'0" - 5'2" |
71 - 75 cm 28" - 30" |
50 |
158 - 163 cm 5'2" - 5'4" |
74 - 77 cm 29" - 30" |
52 |
163 - 168 cm 5'4" - 5'6" |
76 - 79 cm 30" - 31" |
54 |
168 - 174 cm 5'6" - 5'9" |
78 - 82 cm 31" - 32" |
56 |
174 - 180 cm 5'9" - 5'11" |
81 - 85 cm 32" - 33" |
58 |
180 - 185 cm 5'11" - 6'1" |
84 - 87 cm 33" - 34" |
60 |
185 - 190 cm 6'1" - 6'3" |
86 - 90 cm 34" - 35" |
62 |
190 - 195 cm 6'3" - 6'5" |
89 - 92 cm 35" - 36" |
