Trek Emonda SLR 6 AXS
Trek Emonda SLR 6 AXS
Emonda SLR 6 eTap is an ultralight, aerodynamic carbon racing bike designed and built to be the fastest climbing solution we've ever made. The incredible ride quality of our lightest platform and the smooth, precise qualities of the SRAM Rival AXS wireless electronic drivetrain give you maximum speed on any slope.
Specifications
Chassis | Ultralight 800 Series OCLV Carbon, race-optimized carbon tube, tapered head tube, internal cable routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle |
---|---|
Fork | Émonda SLR full carbon, tapered carbon steerer, internal brake cable routing, flat mount disc, 12x100mm thru axle |
Chassis alignment | H1.5 Race |
Weight | 56" - 7.48kg/16.5lbs |
---|---|
Weight Limit | This model has an overall maximum limit (combined weight of bicycle, rider and load) of 125kg. |
Drums | SRAM eTap battery (with charger) |
---|
Command | SRAM Rival eTap AXS, 12 speed |
---|---|
Front derailleur | SRAM Rival D1 AXS, weld-on |
Rear derailleur | SRAM Rival AXS |
*Crankset |
Measure: 47 SRAM Rival AXS with power meter, 48/35, DUB, 165mm length |
Measure: 50, 52 SRAM Rival AXS with power meter, 48/35, DUB, 170mm length |
|
Measure: 54, 56, 58 SRAM Rival AXS with power meter, 48/35, DUB, 172.5mm length |
|
Measure: 60, 62 SRAM Rival AXS Power Meter, 48/35, DUB, 175mm length |
|
Central movement | SRAM DUB, T47 threaded, internal bearing |
Cassette | SRAM XG-1250, 10-36, 12 speed |
Chain | SRAM Rival, 12 speed |
Max. size of the crown | 1x : 50 dts, 2x : 53/39 |
Front wheel | Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim profile, 100x12mm thru axle |
---|---|
Rear wheel | Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim profile, SRAM XD-R drivetrain, 142x12mm thru axle |
Front locking | Bontrager Switch thru axle, removable lever |
Rear locking | Bontrager Switch thru axle, removable lever |
Tire | Bontrager R3 Hard-Case Lite, aramid bead, 120tpi, 700x25mm |
Max. dimensions of the tyre | 28mm |
*Saddle |
Measure: 47, 50, 52 Bontrager Aeolus P2 Elite, 155mm width |
---|---|
Measure: 54, 56, 58, 60, 62 Bontrager Aeolus Elite, austenite rails, 145mm width |
|
*Seatpost |
Measure: 47, 50, 52, 54 Bontrager carbon seatpost terminal, 20mm offset, short length |
Measure: 56, 58, 60, 62 Bontrager alloy seat post, 20mm offset, long length |
|
*Handlebar/stem (integrated) |
Measure: 47, 50 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width, 80mm stem length |
Measure: 52 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 40cm width, 90mm stem length |
|
Measure: 54 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 90mm stem length |
|
Measure: 56 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 100mm stem length |
|
Measure: 58 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 110mm stem length |
|
Measure: 60, 62 Bontrager Aeolus RSL integrated handlebar and stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 44cm width, 110mm stem length |
|
Handlebar tape | Bontrager Supertack Perf Tape |
Brake | SRAM Rival hydraulic disc |
Brake rotor | SRAM Paceline, rounded, centerlock, 160 mm |
Disk size | Max brake rotor size: 160mm front & rear |
We reserve the right to make changes to product information on the site at any time without notice, including equipment, specifications, models, colors, materials and prices. Due to supply chain issues, compatible parts may be replaced at any time without notice.
Bike and frame weights are for pre-production painted products at the time of printing. The weight of the finished product may vary.
Size chart
Measure | Rider height | Inside leg |
---|---|---|
47 |
152 - 158 cm 4'11.8" - 5'2.2" |
71 - 75 cm 28.0" - 29.5" |
50 |
158 - 163 cm 5'2.2" - 5'4.2" |
74 - 77 cm 29.1" - 30.3" |
52 |
163 - 168 cm 5'4.2" - 5'6.1" |
76 - 79 cm 29.9" - 31.1" |
54 |
168 - 174 cm 5'6.1" - 5'8.5" |
78 - 82 cm 30.7" - 32.3" |
56 |
174 - 180 cm 5'8.5" - 5'10.9" |
81 - 85 cm 31.9" - 33.5" |
58 |
180 - 185 cm 5'10.9" - 6'0.8" |
84 - 87 cm 33.1" - 34.3" |
60 |
185 - 190 cm 6'0.8" - 6'2.8" |
86 - 90 cm 33.9" - 35.4" |
62 |
190 - 195 cm 6'2.8" - 6'4.8" |
89 - 92 cm 35.0" - 36.2" |
