Trek Supercaliber 9.8 Gen 1

Name: Trek Supercaliber 9.8 Gen 1
Brand: Trek
SKU: 5278823
Price: 4799.0 EUR
Availability: OutOfStock

€4.799,00

~~€7.199,00~~ €4.799,00

Sale Sold out

Tax included. Shipping calculated at checkout.

Color Purpur TK Weiß/Kies

Cut S M L M/L

Product variants

Quantity

Supercaliber 9.8 is the cross country bike developed for speed and designed to excel in the World Cup. Its configuration includes the exclusive IsoStrut integrated shock absorber combined with a lightweight RockShox fork for a versatile and smooth ride even on the most technical terrain.

Specifications

FRAME KIT:

Chassis	OCLV Mountain Carbon main frame and stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel
Fork	RockShox SID SL, DebonAir spring, Rush RL damper, 44mm offset, Boost110, 15mm Maxle Stealth, 100mm travel
Suspension	Trek IsoStrut, Fox Performance shock, air spring, 2-position DPS remote shock, 235x32.5mm
Suspension lever	Fox 2-position double locking lever
Max. excursion fork compatible	120mm (531mm pin to crown)

WHEELS:

Front wheel	Bontrager Kovee Pro 30 carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Rear wheel	Bontrager Kovee Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, XD drive, 6-bolt, Boost148, 12mm thru axle
Rear locking	Bontrager Switch thru axle, removable lever
Circle	Bontrager Kovee Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Tire	Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength protection, aramid bead, 120 tpi, 29x2.20"
Pneumatic component	Bontrager TLR Sealant, 6oz
Paranipple	Bontrager TLR
Max. dimensions of the tyre	Frame: 29x2.20" Fork: See manufacturer

TRANSMISSION:

Command	SRAM GX Eagle AXS, 12 speed
Rear derailleur	SRAM GX Eagle AXS
*Crankset	Size: S, M SRAM GX Eagle Carbon, DUB, 32T alloy chainring, 52mm chainline, 170mm length
*Crankset	Size: M/L, L, XL SRAM GX Eagle Carbon, DUB, 32T alloy chainring, 52mm chainline, 175mm length
Central movement	SRAM DUB, 92mm, PressFit
Cassette	SRAM Eagle XG-1275, 10-52, 12 speed
Chain	SRAM GX Eagle, 12 speed
Max. size of the crown	36T

COMPONENTS:

Saddle	Bontrager P3 Verse Elite, stainless steel rails, 145mm width
*Seatpost	Size: S Bontrager Pro, OCLV Carbon, 31.6mm, 0mm offset, 330mm length
*Seatpost	Size: M, M/L, L, XL Bontrager Pro, OCLV Carbon, 31.6mm, 0mm offset, 400mm length
*Handlebar + integrated stem	Size: S, M Bontrager RSL integrated handlebar/stem, OCLV carbon, 0mm handlebar rise, 750mm width, -13 degrees stem rise, 70mm length
	Size: M/L, L Bontrager RSL integrated handlebar/stem, OCLV carbon, 0mm handlebar rise, 750mm width, -13 degrees stem rise, 80mm length
	Size: XL Bontrager RSL integrated handlebar/stem, OCLV carbon, 0mm handlebar rise, 750mm width, -13 degrees stem rise, 90mm length
Knobs	ESI Chunky
Headset	Integrated Knock Block, 62° radius, cartridge bearing, 1-1/8" top, 1.5" bottom
Brake	SRAM Level TLM hydraulic disc
*Brake rotor	Size: S, M, M/L, L, XL SRAM CenterLine, 6-bolt, rounded edge, 160mm
*Brake rotor	Size: S, M, M/L, L, XL SRAM CenterLine, 6-bolt, rounded edge, 180mm
Disk size	Max brake rotor size: 180mm front, 160mm rear

WEIGHT:

Weight	M - 10.65 kg / 23.48 lbs
Weight Limit	This bike has a maximum overall weight limit (combined weight of bike, rider and cargo) of 136kg.

*The manufacturer reserves the right to change information on the website without notice, including specifications, models, colors and materials.

*Images are for indicative purposes only and may not correspond to the product description

size-table
Measure	Rider height	Inside leg
S	155 - 165 cm 5'1" - 5'5"	74 - 78 cm 29" - 31"
M	165 - 176 cm 5'5" - 5'9"	79 - 83 cm 31" - 33"
M/L	173 - 180 cm 5'8" - 5'11"	81 - 86 cm 32" - 34"
L	177 - 188 cm 5'10" - 6'2"	84 - 89 cm 33" - 35"
XL	188 - 195 cm 6'2" - 6'5"	89 - 91 cm 35" - 36"
2XL	195 - 203 cm 6'5" - 6'8"	91 - 97 cm 36" - 38"
